Description
Mean Well LED driverLED-switching power supply LPC-35-1400
35W Single Output Switching LED Power Supply
9 ~ 24 Volts @ 1400 Milliamps
Features:
- Constant current design
- Universal AC input / Full range
- Fully encapsulated with IP67 level
- Withstand 300VAC surge input for 5 seconds
- Protections: Short circuit / Over current / Over voltage
- Fully isolated plastic case
- Cooling by free air convection
- UL1310 Class 2 power unit, pass LPS
- 100% full load burn-in test
- Low cost, high reliability
- Suitable for LED lighting and moving sign applications
- 2 years warranty
-
Specification Value Output Current (A) 1.4 Maximum Output Power (W) 33.6 Family LPC-35 Additional Output Voltages (VDC) 9 to 24 Input Voltage (VAC) 90 to 264 Input Frequency 47 to 63 Maximum Input Current (A) 1.1 Output Connector Type Stripped and Tinned Number of Outputs 1 Product Type AC to DC Power Supply Efficiency (%) 85 Minimum Isolation Voltage 3000V Operating Temperature-Min (Cel) -30 Operating Temperature-Max (Cel) 75 Length (inch) 5.82 Width (inch) 1.57 Height (inch) 1.18 Type Auto Switching Style Enclosed
