The Clipsal PIR motion sensor features a robust IP66‑rated housing for reliable outdoor performance. It detects movement up to 18 m within a 110° field of view and offers adjustable sensitivity, lux level, and time‑delay settings. Designed for surface mounting, it supports both wall and ceiling installations at heights up to 2.4 m. The mercury‑free, RoHS‑exempt unit is suitable for residential and commercial lighting control.
| Sensor Type |
PIR |
| Operational Voltage |
200‑265 V AC |
| Rated Current |
10 A |
| Detection Range |
18 m |
| Field of View |
110° |
| IP Rating |
IP66 |
| Mounting Height |
2.4 m |
| Ambient Temperature |
0‑50 °C |
| Mercury Free |
Yes |
| RoHS Exemption |
Yes |
