- Camera
-
Image Sensor1/1.8" Progressive Scan CMOS
-
Min. Illumination0.0014 @ (F1.0, AGC ON), 0 Lux with Light
-
Shutter Speed1/3 s to 1/100,000 s
-
Slow ShutterYes
-
Wide Dynamic Range120 dB
-
Angle AdjustmentPan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360°
- Lens
-
ApertureF1.0
-
FocusFixed
-
Lens Type & FOV2.8 mm, horizontal FOV: 109°, vertical FOV: 55°, diagonal FOV: 138°; 4 mm, horizontal FOV: 94°, vertical FOV: 48°, diagonal FOV: 115°; 6 mm, horizontal FOV: 57°, vertical FOV: 31°, diagonal FOV: 67°
-
Lens MountM16
- Illuminator
-
White Light RangeWarm white LEDs (3000K), up to 30m
- Video
-
Max. Resolution2688 × 1520
-
Main Stream50Hz: 25fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720); 60Hz: 30fps (2688 × 1520, 2560 × 1440, 2304 × 1296, 1920 × 1080, 1280 × 720)
-
Sub Stream50Hz: 25fps (640 × 480, 640 × 360, 320 × 240); 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
-
Third Stream50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288); 60Hz: 30fps(1280 × 720, 640 × 360, 352 × 240)
-
Video CompressionMain stream: H.265+/H.265/H.264+/H.264; Sub-stream: H.265/H.264/MJPEG; Third stream: H.265/H.264
-
H.264 TypeMain Profile/High Profile
-
H.265 TypeMain Profile
-
Video Bit Rate32 Kbps to 16 Mbps
- Audio
-
Audio Compression1 fixed region for main stream and sub-stream separately
-
Audio Bit Rate64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-160Kbps(MP2L2)
-
Environment Noise FilteringYes
-
Audio Sampling Rate8kHz/16kHz/32kHz/44.1kHz/48kHz
- Network
-
Network StoragemicroSD/SDHC/SDXC card (128 GB), local storage and NAS (NFS, SMB/CIFS), ANR
-
ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
-
APIONVIF (PROFILE S, PROFILE G), ISAPI
-
Simultaneous Live ViewUp to 6 channels
-
User/HostUp to 32 users, 3 levels: Administrator, Operator and User
-
ClientiVMS-4200, Hik-Connect, iVMS-4500, iVMS-5200
-
Web BrowserPlug-in required live view: IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11; Plug-in free live view: Chrome 45.0+, Firefox 52.0+
-
Alarm TriggerMotion detection, video tampering detection, network disconnected, IP address conflict, illegal login, HDD full, HDD error
-
Exception DetectionScene change detection
- Image
-
Image EnhancementBLC/3D DNR/HLC
-
Image SettingsRotate mode, saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
-
Day/Night SwitchDay/Night
-
DNR3D DNR
- Interface
-
Communication Interface1 RJ45 10M/100M self-adaptive Ethernet port
-
Audio1 audio input (built-in mic ), mono sound (-U)
-
Hardware ResetYes
-
On-Board StorageBuilt-in Micro SD/SDHC/SDXC slot, up to 128 GB
- Smart Feature-Set
-
Smart EventLine crossing detection, intrusion detection, object removal detection, unattended baggage detection, Face Detection
- General
-
Firmware VersionV5.5.82
-
General FunctionOne-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
-
Startup And Operating Conditions-30 °C to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing)
-
Power Supply12 VDC ± 25%, Φ 5.5 mm coaxial power plug,PoE (802.3af, class 3)
-
Power Consumption And Current12 VDC, 0.5 A, max. 6 W, PoE (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, max. 7.5 W
-
Camera DimensionCamera: Φ 138.3 × 125.2 mm (Φ 5.4" × 4.9"); With package: 170 × 170 × 150 mm (7" × 7" × 5.9")
-
Camera WeightCamera: 575 g (1.3 lb.); With package: 833 g (1.8 lb.)
- Approval
-
Protection-L: IP67 -LU: IP66
